"""Base class for objects of type connectivity."""
import numpy as np
from vispy import scene
import vispy.visuals.transforms as vist
from .visbrain_obj import VisbrainObject, CombineObjects
from ..utils import wrap_properties
from ..visuals import PicMesh
[docs]
class Picture3DObj(VisbrainObject):
"""Create a 3-D picture object.
Parameters
----------
name : string
The name of the connectivity object.
data : array_like
Array of data pictures of shape (n_sources, n_rows, n_columns).
xyz : array_like
The 3-d position of each picture of shape (n_sources, 3).
select : array_like | None
Select the pictures to display. Should be a vector of bolean values
of shape (n_sources,).
pic_width : float | 7.
Width of each picture.
pic_height : float | 7.
Height of each picture.
alpha : float | 1.
Image transparency.
cmap : string | 'viridis'
Colormap to use.
vmin : float | None
Lower threshold of the colormap.
under : string | None
Color to use for values under vmin.
vmin : float | None
Higher threshold of the colormap.
over : string | None
Color to use for values over vmax.
translate : tuple | (0., 0., 1.)
Translation over the (x, y, z) axis.
transform : VisPy.visuals.transforms | None
VisPy transformation to set to the parent node.
parent : VisPy.parent | None
Line object parent.
verbose : string
Verbosity level.
_z : float | 10.
In case of (n_sources, 2) use _z to specify the elevation.
kw : dict | {}
Optional arguments are used to control the colorbar
(See :class:`ColorbarObj`).
Notes
-----
List of supported shortcuts :
* **s** : save the figure
* **<delete>** : reset camera
Examples
--------
>>> import numpy as np
>>> from visbrain.objects import Picture3DObj
>>> n_rows, n_cols, n_pic = 10, 20, 5
>>> data = np.random.rand(n_pic, n_rows, n_cols)
>>> xyz = np.random.uniform(-10, 10, (n_pic, 3))
>>> pic = Picture3DObj('Pic', data, xyz, cmap='plasma')
>>> pic.preview(axis=True)
"""
###########################################################################
###########################################################################
# BUILT IN
###########################################################################
###########################################################################
[docs]
def __init__(self, name, data, xyz, select=None, pic_width=7.,
pic_height=7., alpha=1., cmap='viridis', clim=None, vmin=None,
vmax=None, under='gray', over='red', translate=(0., 0., 1.),
transform=None, parent=None, verbose=None, _z=-10., **kw):
"""Init."""
VisbrainObject.__init__(self, name, parent, transform, verbose, **kw)
self._update_cbar_args(cmap, clim, vmin, vmax, under, over)
# _______________________ CHECKING _______________________
# Data :
assert isinstance(data, np.ndarray) and data.ndim == 3.
self._n_nodes = data.shape[0]
self._minmax = (data.min(), data.max())
# XYZ :
sh = xyz.shape
assert (sh[1] in [2, 3]) and (sh[0] == len(self))
xyz = xyz if sh[1] == 3 else np.c_[xyz, np.full((len(self),), _z)]
self._xyz = xyz.astype(np.float32)
# Select :
assert (select is None) or isinstance(select, (list, np.ndarray))
# Width, height :
assert all([isinstance(k, (int, float)) for k in (pic_height,
pic_width)])
self._pic_width, self._pic_height = pic_width, pic_height
# Translate :
assert len(translate) == 3
tr = vist.STTransform(translate=translate)
self._translate = translate
# Alpha :
assert isinstance(alpha, (int, float)) and (0. <= alpha <= 1.)
self._alpha = alpha
# _______________________ IMAGE _______________________
self._pic = PicMesh(data, xyz, pic_width, pic_height, translate,
select, **self.to_kwargs())
self._pic.transform = tr
self._pic.parent = self._node
def __len__(self):
"""Get the number of pictures."""
return self._n_nodes
def _get_camera(self):
"""Get the most adapted camera."""
d_mean = self._xyz.mean(0)
dist = np.linalg.norm(self._xyz, axis=1).max()
cam = scene.cameras.TurntableCamera(center=d_mean, scale_factor=dist)
self.camera = cam
return cam
[docs]
def update(self):
"""Update image."""
self._pic.update()
###########################################################################
###########################################################################
# PROPERTIES
###########################################################################
###########################################################################
# ----------- PIC_WIDTH -----------
@property
def pic_width(self):
"""Get the pic_width value."""
return self._pic_width
@pic_width.setter
@wrap_properties
def pic_width(self, value):
"""Set pic_width value."""
assert isinstance(value, (int, float))
self._pic_width = value
self._pic.set_data(width=value)
# ----------- PIC_HEIGHT -----------
@property
def pic_height(self):
"""Get the height value."""
return self._pic_height
@pic_height.setter
@wrap_properties
def pic_height(self, value):
"""Set pic_height value."""
assert isinstance(value, (int, float))
self._pic_height = value
self._pic.set_data(height=value)
# ----------- TRANSLATE -----------
@property
def translate(self):
"""Get the translate value."""
return self._translate
@translate.setter
@wrap_properties
def translate(self, value):
"""Set translate value."""
assert len(value) == 3
self._pic.transform.translate = value
self._translate = value
self.update()
# ----------- ALPHA -----------
@property
def alpha(self):
"""Get the alpha value."""
return self._alpha
@alpha.setter
@wrap_properties
def alpha(self, value):
"""Set alpha value."""
assert isinstance(value, (int, float)) and (0. <= value <= 1.)
self._pic.alpha = value
self._alpha = value
class CombinePictures(CombineObjects):
"""Combine pictures objects.
Parameters
----------
pobjs : Picture3DObj/list | None
List of picture objects.
select : string | None
The name of the picture object to select.
parent : VisPy.parent | None
Images object parent.
"""
def __init__(self, pobjs=None, select=None, parent=None):
"""Init."""
CombineObjects.__init__(self, Picture3DObj, pobjs, select, parent)
